Drag Chain Conveyor

Efficient & Reliable Bulk Material Handling

Drag Chain Conveyors are one of the most dependable systems for moving bulk materials smoothly and safely. Instead of belts or buckets, they use a continuous chain with paddles or scrapers to pull material through an enclosed trough. This rugged design makes them ideal for handling challenging materials across a wide range of industries.

Also known as scraper chain conveyors, paddle conveyors, or en-masse conveyors, they efficiently handle powders, granules, cement clinker, ash, sawdust, pellets, sludge, and many other industrial materials requiring controlled, enclosed movement.

Technical Specifications

Parameter Specification
Width Custom-built as per application
Length As per project requirement
Capacity Up to 200 TPH
MOC MS / SS based on requirement

Talk to our experts and build the right solution for your industry.

Inquiry Now

Applications

Drag Chain Conveyors are preferred in environments where materials are dry, hot, abrasive, dusty, or free-flowing.

Power Plants & Waste Processing

Coal, biomass, RDF, sludge, ash handling.

Food Industry

Powders, grains, cereals, snacks, pet food.

Plastic & Rubber

PET flakes, resin, latex, recycled granules.

Timber Industry

Wood chips, sawdust, bark, fibers.

Key Technical Features

  • Drive Unit Assembly – Motor with drive sprocket system
  • Intermediate Casing – Fully enclosed housing
  • Take-Up Unit – Maintains proper chain tension
  • Chain Link Assembly – Heavy-duty chain for tough materials
  • Chain Drive Arrangement – Ensures smooth conveying

How Drag Chain Conveyors Work

The system uses a single or double-strand chain fitted with paddles (flights). The chain drags material along the trough, creating smooth, controlled conveying action.

  • Chain motion drags material forward
  • Material moves by friction and shearing action
  • Paddles create pockets to channel flow
  • Supports multiple inlet points

Advantages of Drag Chain Conveyors

  • Simple and robust construction
  • Low installation and maintenance cost
  • High material handling capacity
  • Energy-efficient operation
  • Fully enclosed, dust-free conveying
  • Suitable for hot, abrasive, or dusty materials
  • Supports horizontal, inclined, or steep conveying
  • Long service life & minimal downtime

Types of Drag Chain Conveyors

  • Scraper Chain Conveyor
  • Apron Chain Conveyor

Available with Trimech Engineers Pvt. Ltd. as complete, high-performance systems.

Why Choose TRIMECH Drag Chain Conveyors?

Trimech is a trusted manufacturer for drag chain conveyors used in:

Steel • Cement • Coal • Mining • Fertilizers • Chemicals • Food Grains • Infrastructure • Ports

  • Designed using precise engineering calculations
  • Capacity up to 200 TPH
  • Manufactured with advanced technology
  • Built for durability, reliability & efficiency
  • Fully customized for any operating conditions

After-Sales Support

  • Free pre-installation assistance
  • Service engineer response within 48 hours
  • Installation & commissioning support
  • Operation & Maintenance manuals
  • User training at site
  • Warranty with repair/replacement support

FAQs

The chain-and-paddle mechanism easily moves hot, abrasive, or heavy materials without damage or clogging.

The conveyor is fully enclosed, preventing dust, spills, and material leakage.

It can be customized in size, layout, and chain configuration to handle various materials efficiently.

Trimech Engineers manufactures high-performance, industry-ready drag chain systems.

Yes, the simple structure and fewer moving parts make maintenance quick and cost-effective.
