Skip Hoist System
Compact & Efficient Vertical Material Lifting Solution
A Skip Hoist System is a compact and efficient material-lifting solution designed to move bulk materials—solid, semi-solid, or liquid—to elevated heights. Built for vertical conveying in limited spaces, skip hoists deliver robust lifting performance without occupying large floor space. Manufactured with modern engineering and high precision, these systems offer long-term reliability at an economical price point.
Technical Specifications
| Technical Parameter | Data |
|---|---|
| Capacity | Up to 30 TPH |
| Height | Up to 25 meters |
| MOC | MS / SS 304 / SS 316 (as per requirement) |
Talk to our experts and build the right solution for your industry.
Inquiry NowHow a Skip Hoist System Works
The Skip Hoist System uses electric winches to lift and lower a heavy-duty skip (bucket) along guided rails. The entire operation is designed for smooth and safe material lifting with automated functions.
- Winches pull the skip upward along internal rails inside a steel frame
- Four wheels ensure smooth travel on four dedicated tracks
- Controlled lifting speed between 0–14 m/min
- Winches at the base & sheaves at the top ensure perfect load balance
- Loader barrier with wheel stoppers ensures safe loading
- Material loading allowed only when skip is in the bottom position
- Skip operated via remote control with automatic discharge at top
- Skip returns to home position for next cycle
This continuous lifting cycle makes skip hoists ideal for a wide range of heavy-duty industrial applications.
Major Components of the TRIMECH Skip Hoist System
- Custom-designed Skip (Bucket)
- Twin Hoisting Cables
- High-performance Electric Winches
- Robust Main Frame Structure
- Loader Barrier with Wheel Stoppers
- Precision Roller-Track Assembly
- Position & Emergency Limit Switches
- Rope Slack Limit Switch
- Rotary End-Stop Switch
Advantages of Skip Hoist Systems
- Suitable for solids, granules, cement, concrete, coal, rocks & more
- Space-saving solution for vertical lifting
- Heavy-duty and long-lasting construction
- Simple, user-friendly operation
- Energy-efficient and low power consumption
- Minimal maintenance (mainly rope replacement)
- Automated and semi-automatic options available
- Handles all shapes and sizes of material
Product USP – Why Trimech?
- Leading manufacturer of premium Skip Hoist Systems
- Available in MS, SS304, SS316, batching & continuous types
- Custom-built skip width & machine size
- Precision-engineered structural frame
- Heavy-duty components for long operational life
- Trusted for continuous vertical lifting operations
After Sales Service
- 48-hour onsite assistance
- Free pre-installation consultation
- Complete Operation & Maintenance Manual
- Expert-led operational training
- Warranty with repair/replacement coverage
- Continuous post-commissioning technical support
